TECHNICAL DATA
AIRTEC huge front mount intercooler for the Mazda 3 MPS Mk1.
A much needed upgrade for your re-mapped Mazda MPS.
- 70mm core with flowed cast end tanks
- High quality silicone hoses supplied with stainless jubilee clips
- Retains original crash bar and fog lights
- No cutting to bumper needed
- Fitting instructions supplied along with all required fittings
- Proven power increase
- Available in pro series black or natural silver
- AIRTEC 3 year unlimited mileage waranty
- Fitting takes approximately 2-3 hours
Test results taken on the AIRTEC demo car
Standard top mount intercooler:
Run 1
In – 160.5 degrees
Out – 70.7 degrees
Run 2
In – 160.6 degrees
Out – 70.4 degrees
Run 3
In – 162.1 degrees
Out – 73.9 degrees
AIRTEC Stage 3 intercooler
Run 1
In – 123.7 degrees
Out – 23.8 degrees
Run 2
In – 119.2 degrees
Out – 22.6 degrees
Run 3
In – 120.1 degrees
Out – 22.8 degrees
Approximate Dimensions:
Width – 740mm (not including pipes)
Height – 170mm
Depth – 70mm
NOW AVAILABLE IN PRO-SERIES BLACK ONLY!
Registered Design Right number: 6023247
