BMW F-Series Front Mount Intercooler Upgrade - 420d 425d 430d 435d - N55 Turbo - F32 F33 F30 F31 F20 F21 F22 F23 F34
Unlock cooler intake temps and consistent performance with this BMW front mount intercooler upgrade. Perfect for BMW 4 Series F32 F33 420d 425d 430d 435d, BMW 3 Series F30 F31 F34, BMW 1 Series F20 F21 and BMW 2 Series F22 F23, as well as N55-powered models like M135i, 335i and 435i. This FMIC is engineered for drivers who want a direct fit, high-flow, bar and plate intercooler that delivers real-world gains in intake air temperature reduction and reliable power on road and track.
We have run this intercooler on our own and customer cars and the results are fantastic. Compared with the standard BMW intercooler the intake temperature after the core drops massively, giving stronger, repeatable performance pull after pull.
Why choose this BMW intercooler upgrade
- 5 inch competition bar and plate core with flowed cast end tanks for optimum charge cooling and pressure drop control
- Four extra rows at the front increase surface area for better heat dissipation
- Internal fin on the intake side directs airflow into the top four extra cores for maximum efficiency
- Near 100 percent more volume and around 90 percent more external surface area than the standard intercooler
- Dimensions 520 mm x 210 mm x 130 mm, the same core sizing as popular premium alternatives
- Approximate weight 11.5 kg for a robust, high-density core
- Direct fit plug and play upgrade for a wide range of BMW F-Series petrol and diesel models
- Professional installation recommended, typical fitting time 1 to 2 hours
Proven intake temperature reductions
In back-to-back road tests across five consecutive pulls:
- Pre-intercooler intake temperatures on the standard unit and this intercooler measured between 135 and 140 degrees
- Post-intercooler temperatures into the engine were 75 to 80 degrees with the standard cooler
- Post-intercooler temperatures with this upgrade dropped into the high 20s across all five runs
Lower IAT means more consistent performance, improved throttle response and reduced heat soak during spirited driving.
Ideal search terms
BMW intercooler upgrade, BMW FMIC, BMW N55 intercooler, BMW 420d intercooler, BMW 430d intercooler, BMW 435d intercooler, BMW F32 intercooler, BMW F33 intercooler, BMW 3 Series F30 F31 intercooler, M135i intercooler, 335i intercooler, 435i intercooler, bar and plate intercooler, front mount intercooler BMW.
Compatible BMW models - direct fit
BMW 1 Series F20 F21
- 114i F20/F21 75 kW 102 PS (2012+)
- 116i F20/F21 100 kW 136 PS (2011+)
- 118i F20/F21 125 kW 170 PS (2011+)
- 125i F20/F21 160 kW 218 PS (2012+)
- M135i F20/F21 235 kW 320 PS (2011+)
- 114d F20/F21 70 kW 95 PS (2012+)
- 116d F20/F21 85 kW 116 PS (2011+)
- 118d F20/F21 105 kW 143 PS (2011+)
- 120d F20/F21 135 kW 184 PS (2011+)
- 125d F20/F21 160 kW 218 PS (2012+)
BMW 2 Series F22 F23
- 220i F22/F23 135 kW 184 PS (2014+)
- 228i F22/F23 180 kW 245 PS (2014+)
- M235i F22/F23 240 kW 326 PS (2014+)
- 218d F22/F23 103 kW 143 PS (2014+)
- 220d F22/F23 135 kW 184 PS (2014+)
- 225d F22/F23 160 kW 218 PS (2014+)
BMW 3 Series F30 F31 F34
- 316i F30/F31/F34 100 kW 136 PS (2011+)
- 320i F30/F31/F34 135 kW 184 PS (2011+)
- 328i(x) F30/F31/F34 180 kW 245 PS (2011+)
- 335i(x) F30/F31/F34 235 kW 320 PS (2011+)
- 316d F30/F31/F34 85 kW 116 PS (2012+)
- 318d F30/F31/F34 105 kW 143 PS (2012+)
- 320d F30/F31/F34 135 kW 184 PS (2011+)
- 325d F30/F31/F34 160 kW 218 PS (2013+)
- 330d F30/F31/F34 190 kW 258 PS (2012+)
- 335d F30/F31/F34 230 kW 313 PS (2013+)
BMW 4 Series F32 F33
- 420i F32/F33 135 kW 184 PS (2013+)
- 428i F32/F33 180 kW 245 PS (2013+)
- 435i F32/F33 225 kW 306 PS (2013+)
- 420d F32/F33 135 kW 184 PS (2013+)
- 425d F32/F33 160 kW 218 PS (2014+)
- 430d F32/F33 190 kW 258 PS (2013+)
- 435d F32/F33 230 kW 313 PS (2013+)
Fitting and support
This intercooler is a direct replacement for the factory unit. There are useful videos online to guide installation. For a hassle-free professional fit, book with Nforcd in Warwickshire. Request a fitting quote at Sales@nforcd.com.
In summary
If you want a BMW intercooler upgrade for F-Series that is plug and play, high flowing and proven to slash intake temperatures, this 5 inch bar and plate front mount intercooler is the choice for BMW 420d 425d 430d 435d, 335i, 435i, M135i and more. Strong cooling, repeatable performance and excellent value. A must-have FMIC for tuned and spirited road cars seeking reliable charge temperature control.
