Part Number: P2000-PCM31MM
Mr12Volt P2000 PCM 3.1 MOST Bus CarPlay and Android Auto Interface with OEM Microphone Support
Upgrade your Porsche infotainment with a premium CarPlay and Android Auto retrofit for PCM 3.1. The Mr12Volt P2000-PCM31MM integrates via the factory MOST Bus for outstanding OEM-like sound and seamless operation. Enjoy wireless and wired Apple CarPlay, Google Android Auto, Bluetooth hands-free and audio streaming, USB video and music playback, Wireless MirrorLink, and flexible camera inputs without changing your head unit. Now with full OEM microphone support for crystal-clear calls and voice control.
This is the go-to Porsche CarPlay retrofit for drivers searching for the cleanest integration on PCM3.1, delivering high-end sound quality, factory-style control, and an easy way to modernise your cockpit with navigation, music, calls, and messaging from your phone.
Vehicle Compatibility — PCM 3.1
- Porsche 911 2012–2016
- Porsche Boxster / Cayman 2013–2016
- Porsche Panamera / Cayenne 2010–2016
- Porsche Macan 2014–2016
Key Features
- OEM microphone support for factory-quality voice calls and voice commands
- MOST Bus integration for high-end audio and OEM-like functionality
- Wireless and wired Apple CarPlay and Android Auto
- Wireless MirrorLink
- Bluetooth hands-free calling and A2DP audio streaming
- USB media playback for video and music
- Reverse, front, left or right camera inputs — supports aftermarket cameras up to AHD720
- Apple Lossless music streaming support
- Highly customisable 15‑bar DSP equaliser for fine-tuned sound
How It Works
- Select Mr12Volt through the TV function on the PCM
- No coding and no factory TV module required; once installed, the TV icon appears on the PCM home menu
- Retains OEM feel and integrates cleanly with the existing PCM 3.1 system
Important Notes
- If your Porsche has OEM TV built in, do not purchase this product yet, as the OEM rear camera will not function properly. Please wait for a future updated version.
- Base audio cars with no fibre optic (FO) cable in the harness: follow the video below to modify the supplied FO Y‑cable to a direct male‑to‑male cable.
P2000 Supported Multimedia Formats
- H.264 Baseline/Main/High Profile Level 1–4.2, up to 30 fps @1080p
- VC‑1 Simple/Main/Advanced Profile, levels 0–3, up to 30 fps @1080p
- MPEG‑1/2/4 Simple and Main Profiles, ASP levels 0–5, up to 30 fps @1080p
- RealVideo 8/9/10 up to 30 fps @1080p
- VP6/7/8 including WebM, up to 30 fps @1080p
- DivX 3/4/5/6 up to 30 fps @1080p
- H.263 Profile 0, levels 10–70, up to 30 fps @720x576
- JPEG codec Baseline interleaved up to 8176x8176
- Video files: mkv, mp4, avi, wmv, rmvb, rm, mpg, mpeg, ts, dat, asf, flv, vob and more
- Audio codecs: MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE, AMR and more
Additional Technical Data
- Operating temperature: −20 to +80 °C
- DAC resolution: 18‑bit
- MP3 bit rate: 8–384 kbit
- Voltage: 10–14.6 V DC
- Operating current: 450 mA (700 mA when charging a mobile phone)
- S/N ratio: 95 dB
- Total harmonic distortion: 0.1%
- Frequency response: 20 Hz–20 kHz
Professional Fitting and Support
For a seamless installation on your Porsche PCM 3.1, we recommend professional fitting with Nforcd in Warwickshire. Request a fitting quote at Sales@nforcd.com.
